Yanmar B95W - Page 23

B95W
Safety
03_Sicherheit_en.fm - V 0.1 - 1.8.17
21 / 306
3
46
Fig. 3-3 Positioning of the safety signs - view from in front
1 Risk of scalding from hot, pressurized fluids
2 Risk of injury from pressurized containers
3 Risk of burning from hot surfaces
4 Risk of injury from the articulated area
5 Risk of injury from fluids spraying out, which may get underneath the skin
6 Emergency exit
4
45
123
123
5
6
6
