B95W
Operation
07_Bedienung_en.fm - V1.0 - 1.8.17
243 / 306
7
26
Actuation of oscillating axle lock
The oscillating axle lock is controlled by the excavator brake; that is, upon
engaging the brake, the oscillating axle is automatically locked.
For special application cases, it is possible to activate the oscillating axle locking
independent of the excavator brake.
Turn on the oscillating axle lock.
J The indicator light in the switch lights up red.
Bucket change-over with fork carrier fitted (optional)
Switch on the bucket changeover on the display in the machine functions
sub-menu.
Joystick right
Tab. 7-7 Bucket change-over with fork carrier fitted
Notice
Before locking the oscillation axle, stabilize the machine using the supports.
Notice
After completing the special work, set switch for oscillating axle locking
immediately back to “OFF”.
Position/actuation Effect
to the left Tilt fork carrier back
to the right Tilt fork carrier forward.
