B95W
Transport
08_Transport_en.fm - V1.0 - 1.8.17
263 / 306
8
27
Opening the “travel” oil circuit (not for B95W with high-speed version)
Fig. 8-2 Hydraulic Pump
1 Limiting valve
2 Screw
A = Hydraulic pump
B = Valve
When the swing loader is towed the “travel” oil circuit must be opened so that
the hydrostatic transmission no longer acts as an auxiliary brake.
At the two high-pressure relief valves (1) with bypass, located on top and
bottom, loosen the screw (2) by no more than 3 turns.
After towing, turn the screws (2) back in fully.
