Yanmar B95W - Page 288

B95W
Technical data
286 / 306
9
09_Technische Daten_en.fm - V1.0 - 1.8.17
29
Circular boom
Circular boom with additional weight
Load distance from middle of slewing ring
Bucket hinge pin
height
3 m 4 m 5 m 6 m 7 m
longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral
3.0 m A
4.4 3.8 2.5 2.5 1.7 1.7 1.7 1.0 1.3 0.8
V
3.3 3.6 2.2 2.3 1.3 1.6 0.9 1.1 0.7 0.7
1.5 m A
4.8 3.1 2.8 2.0 2.1 1.4 1.6 1.0 0.8 0.8
V
2.7 2.9 1.8 1.9 1.2 1.3 0.9 0.9 0.6 0.7
0.0 m A
5.3 2.7 3.3 1.8 2.2 1.3 1.5 1.0 0.5 0.6
V
2.3 2.4 1.5 1.7 1.1 1.2 0.8 0.9 0.5 0.6
-1.0 m A
4.4 2.6 2.9 1.8 1.6 1.3 1.1 1.1 0.3 0.4
V
2.3 2.4 1.5 1.6 1.1 1.2 0.9 0.9 0.3 0.4
Load distance from middle of slewing ring
Bucket hinge pin
height
3 m 4 m 5 m 6 m 7 m
longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral
3.0 m A
4.2 4.1 2.5 2.7 1.7 1.6 1.7 1.1 1.3 0.9
V
3.7 3.9 2.4 2.5 1.8 1.6 1.0 1.1 0.8 0.8
1.5 m A
4.8 3.3 2.6 2.1 2.1 1.5 1.7 1.1 0.9 0.6
V
2.9 3.1 1.9 2.1 1.4 1.5 1.0 1.1 0.7 0.6
0.0 m A
5.1 2.8 3.2 1.9 2.2 1.4 1.5 1.0 0.4 0.4
V
2.5 2.7 1.7 1.8 1.3 1.3 0.9 1.0 0.4 0.4
-1.0 m A
4.3 2.8 2.8 1.8 1.9 1.4 1.0 1.2 0.3 0.3
V
2.4 2.7 1.7 1.8 1.2 1.3 1.0 1.1 0.3 0.3
