Yanmar B95W - Page 289

B95W
Technical data
09_Technische Daten_en.fm - V1.0 - 1.8.17
287 / 306
9
29
Monobloc offset boom
Monobloc offset boom with additional weight
Load distance from middle of slewing ring
Bucket hinge pin
height
3 m 4 m 5 m 6 m 7 m
longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral
3.0 m A
------1.71.11.90.9
V
------0.91.00.70.8
1.5 m A
- - 4.4 1.9 3.0 1.3 2.3 1.0 1.8 0.8
V
- - 1.6 1.8 1.1 1.2 0.9 0.9 0.7 0.7
0.0 m A
- - 5.3 1.7 3.2 1.3 2.3 0.9 1.7 0.8
V
- - 1.4 1.5 1.1 1.2 0.8 0.9 0.7 0.6
-1.0 m A
- 2.4 4.4 1.6 2.8 1.2 1.9 0.9 1.6 0.8
V
2.2 2.3 1.4 1.5 1.1 1.1 0.8 0.9 0.8 0.8
Load distance from middle of slewing ring
Bucket hinge pin
height
3 m 4 m 5 m 6 m 7 m
longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral longitu-
dinal
lateral
3.0 m A
------1.91.11.91.0
V
------1.01.10.80.9
1.5 m A
- - 4.4 2.0 2.9 1.5 2.3 1.1 1.8 0.9
V
- - 1.8 1.9 1.3 1.4 1.0 0.8 0.8 0.8
0.0 m A
- - 5.3 1.9 3.2 1.3 2.3 1.1 1.7 0.9
V
- - 1.7 1.7 1.2 1.3 0.9 1.0 0.8 0.8
-1.0 m A
- 2.9 4.3 1.8 2.8 1.4 1.9 1.1 1.6 1.0
V
2.4 2.5 1.6 1.7 1.2 1.3 0.9 1.0 0.9 0.9
