Tab. 5-1 Fuse allocation A1 - A4
F4 5 A Display F14 10 A Power supply SPU
F5 10 A Power supply SPU F15 10 A Power supply SPU
F6 10 A Power supply SPU F16 5 A Key pad
F7 10 A Power supply SPU F17 5 A Pressure switch brake
F8 10 A Power supply SPU F18 5 A Pressure switch travel
F9 10 A Power supply SPU F19 5 A Switch travel drive
F10 10 A Power supply SPU F20 5 A Sensors four-wheel steering
Fuse block A3 (terminal 15)
F1 10 A Working hydraulics F11 10 A Windshield washing/wiping
system
F2 5 A Outrigger F12 5 A Radio
F3 5 A Joystick right F13 15 A Heating control
F4 5 A Joystick left F14 5 A Central lubrication system
F5 5 A Switch console F15 20 A Central lubrication system
F6 15 A Changeover ISO/SAE F16 20 A Refueling pump
F7 5 A Load warning F17 20 A Comfort seat
F8 5 A Hydraulic oil level F18 10 A Mirror heating
F9 5 A Auto-idling system F19 10 A Telematic system
F10 10 A Direction indicators F20 5 A Spare
Fuse block A4 (lighting system)
F1 15 A High beam F14 5 A Spare
F2 15 A Dipped beam F15 5 A Reversing camera
F3 5 A Side lights, left F16 20 A AdBlue
®
heating supply
module
F4 5 A Side lights, right F17 5 A Spare
F11 10 A NOx sensor before the SCR
catalytic converter
F18 5 A Spare
F12 10 A NOx sensor after the SCR
catalytic converter
F19 5 A Spare
F13 5 A Spare F20 5 A Spare
