B95W
Description
05_Beschreibung_en.fm - V1.0 - 1.8.17
77 / 306
5
11
Submenu,
Machine
functions
Activate by selecting menu
Fig. 5-21 Submenu, machine functions
Tab. 5-7 Pictograms of machine functions
Sym-
bol
Description Sym-
bol
Description
Four-wheel mode (optional) Four-wheel crab (optional)
Bucket changeover (optional) ISO - SAE changeover
(optional)
ECO mode (optional) Particle filter regeneration
(optional)
Auto-idle
(optional)
Ash lamp (optional)
Display for position of front axle
steering equipment position
(optional)
Display for position of rear
axle steering equipment
position (optional)
Period for automatic engine
shutoff (optional)
Notice
When in inactive state, the submenu is locked.
Notice
These symbols are illuminated in orange on the symbol bar when they are
activated.
