1.10 o: Operator Related Settings
These parameters control the various functions, features, and display of the digital operator.
u
o1: Digital Operator Display Selection
These parameters determine the data display on the digital operator.
n
o1-01: Drive Mode Unit Monitor Selection
When o1-02 is set to 5, any U monitors can be displayed. This parameter will select the monitors. Pressing the up arrow key
will display the following data: frequency reference → rotational direction → output frequency → output current → o1-01
selection.
Parameter o1-01 selects the content of the last monitor in this sequence. This is done by entering the “1oo” part of
“U1-oo”. Certain monitors are not available in some control modes. There is no effect like this on an LCD operator.
No. Name Setting Range Default
o1-01 Drive Mode Unit Monitor Selection
104 to 813
U1-04 (Control Mode) to
U8-13 (DWEZ Custom
Monitor 3)
<1>
106 (U1-06)
<1>
U2-oo and U3-oo parameters cannot be selected.
n
o1-02: User Monitor Selection after Power Up
Selects which monitor parameter is displayed upon power up. Refer to U: Monitor Parameters on page 171 for a list of
monitors.
No. Name Setting Range Default
o1-02 User Monitor Selection after Power Up 1 to 5 1
Setting 1: Frequency Reference (U1-01)
Setting 2: Motor Direction
Setting 3: Output Frequency (U1-02)
Setting 4: Output Current (U1-03)
Setting 5: User-selected Monitor (Set by o1-01)
n
o1-03: Digital Operator Display Selection
Sets the units used to display the frequency reference and output frequency. Set o1-03 to 3 for user-set units before setting
parameters o1-10 and o1-11.
No. Name Setting Range Default
o1-03 Digital Operator Display Selection 0 to 3
Determined by
A1-02
Setting 0: 0.01 Hz Units
Setting 1: 0.01% Units (100% = Max. Output Frequency)
Setting 2: r/min Units (Calculated by the Max. Output Frequency and the No. of Motor Poles)
Setting 3: User-set Units (Use o1-10, o1-11)
Set the value used for the maximum frequency reference to o1-10. Set the placement of the decimal point in this number to
o1-11.
For example, to have the maximum output frequency displayed as “100.00”, set o1-10 = 10000 and o1-11 = 2 (i.e., 10000
with 2 decimal points).
Note: 1. Parameter o1-03 allows the programmer to change the units used in the following parameters and monitors:
U1-01: frequency reference
1.10 o: Operator Related Settings
