A.5 C: Tuning
C parameters are used to adjust the acceleration and deceleration times, S-curves, slip compensation, torque compensation,
and carrier frequency selections.
u
C1: Acceleration and Deceleration Times
No.
(Addr.
Hex)
Name Description Values Page
C1-01
(200)
Acceleration Time 1
All Modes
Sets the time to accelerate from 0 to maximum frequency.
Default: 10.0 s
Min.: 0.0
Max.: 6000.0
<1>
46
C1-02
(201)
Deceleration Time 1
All Modes
Sets the time to decelerate from maximum frequency to 0.
46
C1-03
(202)
Acceleration Time 2
All Modes
Sets the time to accelerate from 0 to maximum frequency.
Default: 10.0 s
Min.: 0.0
Max.: 6000.0
<1>
46
C1-04
(203)
Deceleration Time 2
All Modes
Sets the time to decelerate from maximum frequency to 0.
46
C1-05
(204)
Acceleration Time 3 (Motor
2 Accel Time 1)
All Modes
Sets the time to accelerate from 0 to maximum frequency.
Default: 10.0 s
Min.: 0.0
Max.: 6000.0
<1>
46
C1-06
(205)
Deceleration Time 3 (Motor
2 Decel Time 1)
All Modes
Sets the time to decelerate from maximum frequency to 0.
46
C1-07
(206)
Acceleration Time 4 (Motor
2 Accel Time 2)
All Modes
Sets the time to accelerate from 0 to maximum frequency.
Default: 10.0 s
Min.: 0.0
Max.: 6000.0
<1>
46
C1-08
(207)
Deceleration Time 4 (Motor
2 Decel Time 2)
All Modes
Sets the time to decelerate from maximum frequency to 0.
46
C1-09
(208)
Fast Stop Time
All Modes
Sets the time for the Fast Stop function.
Default: 10.0 s
Min.: 0.0
Max.: 6000.0
<1>
47
C1-10
(209)
Accel/Decel Time Setting
Units
All Modes
0: 0.01 s (0.00 to 600.00 s)
1: 0.1 s (0.0 to 6000.0 s)
Default: 1
Range: 0, 1
48
C1-11
(20A)
Accel/Decel Time
Switching Frequency
All Modes
Sets the frequency to switch between accel/decel time settings
Default: 0.0 Hz
Min.: 0.0
Max.: 400.0
47
