Register No. Contents
00E5H
oFC3x Contents (CN5-C)
bit 0 Comm. ID Error (oFC30)
bit 1 Model Code Error (oFC31)
bit 2 Sumcheck Error (oFC32)
bit 3 Comm. option timeout waiting for response (oFC33)
bit 4 MEMOBUS Timeout (oFC34)
bit 5 Drive timeout waiting for response (oFC35)
bit 6 CI Check Error (oFC36)
bit 7 Drive timeout waiting for response (oFC37)
bit 8 Control Command Selection Error (oFC38)
bit 9 Drive timeout waiting for response (oFC39)
bit A Control Response Selection 1 Error (oFC40)
bit B Drive timeout waiting for response (oFC41)
bit C Control Response Selection 2 Error (oFC42)
bit D Control Response Selection Error (oFC43)
bit E, F Reserved
00E6H to 00FFH Reserved
<1> Parameter o1-03, Digital Operator Display Selection, determines the units.
<2> The number of decimal places in the parameter value depends on the drive model and the ND/HD selection in parameter C6-01. This value has two
decimal places (0.01 A) if the drive is set for a maximum applicable motor capacity up to and including 11 kW, and one decimal place (0.1 A) if
the maximum applicable motor capacity is higher than 11 kW.
<3> Communication error contents are saved until the fault is reset.
<4> Set the number of motor poles to parameter E2-04, E4-04, or E5-05 depending on the motor being used.
<5> Terminals H1, H2, DM+, and DM- on 600 V class models are designed to the functionality, but are not certified to EN61800-5-1, ISO13849 Cat.
3, IEC/EN61508 SIL2, Insulation coordination: class 1.
u
Broadcast Messages
Data can be written from the master to all slave devices at the same time.
The slave address in a broadcast command message must be set to 00H. All slaves will receive the message, but will not
respond.
Register No. Contents
0001H
Digital Input Command
bit 0 Forward Run (0: Stop 1: Run)
bit 1 Direction Command (0: Forward, 1: Reverse)
bit 2, 3 Reserved
bit 4 External Fault
bit 5 Fault Reset
bit 6 to B Reserved
bit C Multi-Function Digital Input S5
bit D Multi-Function Digital Input S6
bit E Multi-Function Digital Input S7
bit F Multi-Function Digital Input S8
0002H Frequency Reference 30000/100%
B.9 MEMOBUS/Modbus Data Table
340
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
