YASKAWA A1000 HHP - L4: Speed Detection

No.
(Addr.
Hex)
Name Description Values Page
L3-22
(4F9)
Deceleration Time at Stall
Prevention during
Acceleration
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
OLV/PM
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
OLV/PM
Sets the deceleration time used for Stall Prevention during acceleration in
OLV/PM.
Default: 0.0 s
Min.: 0.0
Max.: 6000
142
L3-23
(4FD)
Automatic Reduction
Selection for Stall
Prevention during Run
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f V/f w PG
0: Sets the Stall Prevention level set in L3-04 that is used throughout the entire
frequency range.
1: Automatic Stall Prevention level reduction in the constant output range. The
lower limit value is 40% of L3-06.
Default: 0
Range: 0, 1
144
L3-27
(456)
Stall Prevention Detection
Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
Sets the time the current must exceed the Stall Prevention level to activate
Stall Prevention.
Default: 50 ms
Min.: 0
Max.: 5000
145
<1> Upper limit is dependent on parameters C6-01, Drive Duty Selection, and L8-38, Frequency Reduction Selection.
<2> The setting range is 0 to 2 in OLV/PM control mode. The setting range is 0 and 1 in CLV or AOLV/PM control modes.
<3> Default setting is dependent on parameter E1-01, Input voltage Setting.
<8> Values shown are specific to 400 V class drives. Multiply the value by 1.4375 for 575 V class drives. Multiply the value by 1.725 for 690 V class
drives.
u
L4: Speed Detection
No.
(Addr.
Hex)
Name Description Values Page
L4-01
(499)
Speed Agreement Detection
Level
All Modes
L4-01 sets the frequency detection level for digital output functions
H2-oo = 2, 3, 4, 5.
Default: 0.0 Hz
Min.: 0.0
Max.: 150.0
145
L4-02
(49A)
Speed Agreement Detection
Width
All Modes
L4-02 sets the hysteresis or allowable margin for speed detection.
Default:
<1>
Min.: 0.0
Max.: 20.0
145
L4-03
(49B)
Speed Agreement Detection
Level (+/-)
All Modes
L4-03 sets the frequency detection level for digital output functions
H2-oo = 13, 14, 15, 16.
Default: 0.0 Hz
Min.: -150.0
Max.: 150.0
145
L4-04
(49C)
Speed Agreement Detection
Width (+/-)
All Modes
L4-04 sets the hysteresis or allowable margin for speed detection.
Default:
<1>
Min.: 0.0
Max.: 20.0
145
L4-05
(49D)
Frequency Reference Loss
Detection Selection
All Modes
0: Stop. Drive stops when the frequency reference is lost.
1: Run. Drive runs at a reduced speed when the frequency reference is lost.
Default: 0
Range: 0, 1
146
L4-06
(4C2)
Frequency Reference at
Reference Loss
All Modes
Sets the percentage of the frequency reference that the drive should run with
when the frequency reference is lost.
Default: 80%
Min.: 0.0
Max.: 100.0
146
L4-07
(470)
Speed Agreement Detection
Selection
All Modes
0: No detection during baseblock.
1: Detection always enabled.
Default: 0
Range: 0, 1
146
<1> Default setting is dependent on parameter A1-02, Control Method Selection.
A.10 L: Protection Function
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
285
A
Parameter List
