YASKAWA A1000 HHP User Manual

No.
(Addr.
Hex)
Name Description Values Page
b1-16
(1C5)
Run Command
Selection 2
All Modes
Enabled when a terminal set for “External reference” (H1-oo = 2) closes.
0: Digital operator
1: Digital input terminals
2: MEMOBUS/Modbus communications
3: Option card
Default: 0
Range: 0 to 3
25
b1-17
(1C6)
Run Command at Power Up
All Modes
0: Disregarded. A new Run command must be issued after power up.
1: Allowed. Motor will start immediately after power up if a Run command
is already enabled.
Default: 0
Range: 0, 1
25
<1> Settings 2 and 3 are not available in CLV.
u
b2: DC Injection Braking and Short Circuit Braking
No.
(Addr.
Hex)
Name Description Values Page
b2-01
(189)
DC Injection Braking Start
Frequency
All Modes
Sets the frequency at which DC Injection Braking starts when “Ramp to stop”
(b1-03 = 0) is selected.
Default:
<1>
Min.: 0.0 Hz
Max.: 10.0 Hz
25
b2-02
(18A)
DC Injection Braking
Current
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
Sets the DC Injection Braking current as a percentage of the drive rated current.
Default: 50%
Min.: 0
Max.: 100
26
b2-03
(18B)
DC Injection Braking Time
at Start
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
CLV/PM
CLV
Sets DC Injection Braking (Zero Speed Control when in CLV and CLV/PM)
time at start. Disabled when set to 0.00 seconds.
Default: 0.00 s
Min.: 0.00
Max.: 10.00
26
b2-04
(18C)
DC Injection Braking Time
at Stop
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
CLV/PM
CLV
Sets DC Injection Braking (Zero Speed Control when in CLV and CLV/PM)
time at stop.
Default:
<1>
Min.: 0.00 s
Max.: 10.00 s
26
b2-08
(190)
Magnetic Flux
Compensation Value
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
Sets the magnetic flux compensation as a percentage of the no-load current
value (E2-03).
Default: 0%
Min.: 0
Max.: 1000
27
<1> Default setting is determined by parameter A1-02, Control Method Selection.
A.4 b: Application
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
241
A
Parameter List

YASKAWA A1000 HHP Specifications

General

Series	A1000
Overload Capacity	150% for 60 seconds
Horsepower	0.5-1000 HP
Control Method	V/f Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Ground Fault
Communication	Modbus, DeviceNet, Profibus, Ethernet/IP
Input Voltage	200-240 V, 380-480 V
Output Voltage	0-Input Voltage
Frequency	400 Hz
Power Range	0.4-630 kW
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% RH (non-condensing)
Enclosure Rating	IP20, IP00
Voltage	200-480 V
