YASKAWA A1000 HHP User Manual

No.
(Addr
Hex.)
Name Description Values Page
d6-06
(2A5)
Field Forcing Limit
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVOLV CLV
Sets the upper limit of the excitation current command during magnetic field
forcing. A setting of 100% is equal to motor no-load current. Disabled only
during DC Injection Braking.
Default: 400%
Min.: 100
Max.: 400
73
u
d7: Offset Frequency
No.
(Addr.
Hex)
Name Description Setting Page
d7-01
(2B2)
Offset Frequency 1
All Modes
Added to the frequency reference when the digital input “Frequency offset 1”
(H1-oo = 44) is switched on.
Default: 0.0%
Min.: -100.0
Max.: 100.0
73
d7-02
(2B3)
Offset Frequency 2
All Modes
Added to the frequency reference when the digital input “Frequency offset 2”
(H1-oo = 45) is switched on.
Default: 0.0%
Min.: -100.0
Max.: 100.0
73
d7-03
(2B4)
Offset Frequency 3
All Modes
Added to the frequency reference when the digital input “Frequency offset 3”
(H1-oo = 46) is switched on.
Default: 0.0%
Min.: -100.0
Max.: 100.0
73
A.6 d: References
256
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual

YASKAWA A1000 HHP Specifications

General

Series	A1000
Overload Capacity	150% for 60 seconds
Horsepower	0.5-1000 HP
Control Method	V/f Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Ground Fault
Communication	Modbus, DeviceNet, Profibus, Ethernet/IP
Input Voltage	200-240 V, 380-480 V
Output Voltage	0-Input Voltage
Frequency	400 Hz
Power Range	0.4-630 kW
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% RH (non-condensing)
Enclosure Rating	IP20, IP00
Voltage	200-480 V
