<2> Default setting is dependent on parameter E1-01, Input voltage Setting.
<3> Values shown are specific to 400 V class drives. Multiply the value by 1.4375 for 575 V class drives. Multiply the value by 1.725 for 690 V class
drives.
<4> Setting range value is dependent on parameter C1-10, Accel/Decel Time Setting Units. When C1-10 = 0 (units of 0.01 seconds), the setting range
becomes 0.00 to 600.00 seconds.
<5> Values shown are specific to 400 V class drives. Multiply the value by 1.4375 for 575 V class drives. Multiply the value by 1.725 for 690 V class
drives.
u
L3: Stall Prevention
No.
(Addr.
Hex)
Name Description Values Page
L3-01
(48F)
Stall Prevention Selection
during Acceleration
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
0: Disabled.
1: General purpose. Acceleration is paused as long as the current is above the
L3-02 setting.
2: Intelligent. Accelerate in the shortest possible time without exceeding the
L3-02 level.
Note: Setting 2 is not available when using OLV/PM.
Default: 1
Range: 0 to 2
140
L3-02
(490)
Stall Prevention Level
during Acceleration
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
Used when L3-01 = 1 or 2. 100% is equal to the drive rated current.
Default:
<1>
Min.: 0%
Max.: 150%
<1>
142
L3-03
(491)
Stall Prevention Limit
during Acceleration
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG OLV
Sets Stall Prevention lower limit during acceleration when operating in the
constant power range. Set as a percentage of drive rated current.
Default: 50%
Min.: 0
Max.: 100
142
L3-04
(492)
Stall Prevention Selection
during Deceleration
All Modes
0: Disabled. Deceleration at the active deceleration rate. An ov fault may
occur.
1: General purpose. Deceleration is paused when the DC bus voltage exceeds
the Stall Prevention level.
2: Intelligent. Decelerate as fast as possible while avoiding ov faults.
3: Stall Prevention with braking resistor. Stall Prevention during deceleration
is enabled in coordination with dynamic braking.
4: Overexcitation Deceleration. Decelerates while increasing the motor flux.
5: Overexcitation Deceleration 2. Adjust the deceleration rate according to the
DC bus voltage.
Note:
Setting 3 is not available in models CIMR-Ao4A0930 and
4A1200. A1000 HHP models only have settings 0, 1, 4, and 5.
Default: 1
Range: 0 to 5
<2>
142
L3-05
(493)
Stall Prevention Selection
during Run
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PGV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
0: Disabled. Drive runs at a set frequency. A heavy load may cause speed loss.
1: Decel time 1. Uses the deceleration time set to C1-02 while Stall Prevention
is performed.
2: Decel time 2. Uses the deceleration time set to C1-04 while Stall Prevention
is performed.
Default: 1
Range: 0 to 2
143
L3-06
(494)
Stall Prevention Level
during Run
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PGV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f
OLV/PM
V/f w PG
Enabled when L3-05 is set to 1 or 2. 100% is equal to the drive rated current.
Default:
<1>
Min.: 30%
Max.: 150%
<1>
144
L3-11
(4C7)
Overvoltage Suppression
Function Selection
All Modes
Enables or disables the ov suppression function, which allows the drive to
change the output frequency as the load changes to prevent an ov fault.
0: Disabled
1: Enabled
Default: 0
Range: 0, 1
144
L3-17
(462)
Target DC Bus Voltage for
Overvoltage Suppression
and Stall Prevention
All Modes
Sets the desired value for the DC bus voltage during overvoltage suppression
and Stall Prevention during deceleration.
Default: 370 Vdc
<3> <8>
Min.: 150
Max.: 400
<8>
145
A.10 L: Protection Function
284
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
