A.17 V/f Pattern Default Values
The following table shows the V/f pattern setting default values depending on the control mode (A1-02) and the V/f pattern
selection (E1-03 in V/f Control) for all HHP models:
• 400 V Class 414 A to 2000 A Heavy Duty, 466 A to 2250 A Normal Duty,
• 575 V Class 414 A to 2000 A Heavy Duty, 466 A to 2250 A Normal Duty,
• 690 V Class 414 A to 2000 A Heavy Duty, 466 A to 2250 A Normal Duty.
Table A.4 E1-03 V/f Pattern Settings for Drive Capacity:
No. Unit V/f Control
OLV CLV
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E
F
<1>
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 150.0 60.0 60.0 60.0
E1-05
<3>
V 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 400.0 460.0 460.0 460.0
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0 60.0
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 3.0 3.0 0.0
E1-08
<3>
V 24.0 24.0 24.0 24.0 70.0 100.0 70.0 100.0 30.0 40.0 30.0 40.0 24.0 24.0 24.0 27.6 25.4 0.0
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.5 0.5 0.0
E1-10
<3>
V 12.0 12.0 12.0 12.0 10.0 12.0 10.0 12.0 14.0 18.0 14.0 22.0 12.0 12.0 12.0 13.8 4.6 0.0
<1> This value determines the default values for E1-04 through E1-10 (E3-04 through E3-10 for motor 2).
<3> Values shown here are specific to 400 V class drives. Multiply the values by 1.4375 for 575 V class drives. Multiply the values by 1.725 for 690
V class drives.
