H4: Analog Outputs
No.
(Addr.
Hex)
Name Description Values Page
H4-01
(41D)
Multi-Function Analog
Output Terminal FM
Monitor Selection
All Modes
Selects the data to be output through multi-function analog output terminal
FM.
Set the desired monitor parameter to the digits available in Uo-oo.
For example, enter “103” for U1-03.
Default: 102
Range: 000 to 999
121
H4-02
(41E)
Multi-Function Analog
Output Terminal FM Gain
All Modes
Sets the signal level at terminal FM that is equal to 100% of the selected
monitor value.
Default: 100.0%
Min.: -999.9
Max.: 999.9
121
H4-03
(41F)
Multi-Function Analog
Output Terminal FM Bias
All Modes
Sets the signal level at terminal FM that is equal to 0% of the selected monitor
value.
Default: 0.0%
Min.: -999.9
Max.: 999.9
121
H4-04
(420)
Multi-Function Analog
Output Terminal AM
Monitor Selection
All Modes
Selects the data to be output through multi-function analog output terminal
AM.
Set the desired monitor parameter to the digits available in Uo-oo.
For example, enter “103” for U1-03.
Default: 103
Range: 000 to 999
121
H4-05
(421)
Multi-Function Analog
Output Terminal AM Gain
All Modes
Sets the signal level at terminal AM that is equal to 100% of the selected
monitor value.
Default: 50.0%
Min.: -999.9
Max.: 999.9
121
H4-06
(422)
Multi-Function Analog
Output Terminal AM Bias
All Modes
Sets the signal level at terminal AM that is equal to 0% of the selected monitor
value.
Default: 0.0%
Min.: -999.9
Max.: 999.9
121
H4-07
(423)
Multi-Function Analog
Output Terminal FM Signal
Level Selection
All Modes
0: 0 to 10 V
1: -10 to 10 V
Default: 0
Range: 0, 1
122
H4-08
(424)
Multi-Function Analog
Output Terminal AM Signal
Level Selection
All Modes
0: 0 to 10 V
1: -10 to 10 V
Default: 0
Range: 0, 1
122
u
H5: MEMOBUS/Modbus Serial Communication
No.
(Addr.
Hex)
Name Description Values Page
H5-01
(425)
<1>
Drive Node Address
All Modes
Selects drive station node number (address) for MEMOBUS/Modbus
terminals R+, R-, S+, S-. Cycle power for the setting to take effect.
Default: 1F (Hex)
Min.: 0
Max.: FF
122
H5-02
(426)
Communication Speed
Selection
All Modes
0: 1200 bps
1: 2400 bps
2: 4800 bps
3: 9600 bps
4: 19200 bps
5: 38400 bps
6: 57600 bps
7: 76800 bps
8: 115200 bps
Cycle power for the setting to take effect.
Default: 3
Range: 0 to 8
123
H5-03
(427)
Communication Parity
Selection
All Modes
0: No parity
1: Even parity
2: Odd parity
Cycle power for the setting to take effect.
Default: 0
Range: 0 to 2
123
