YASKAWA A1000 HHP User Manual

H2 Multi-Function Digital Output Settings
H2-oo
Setting
Function Description Page
3C LOCAL/REMOTE status
All Modes
Open: REMOTE
Closed: LOCAL
114
3D During speed search
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLV
Closed: Speed Search is being executed.
114
3E PID feedback low
All Modes
Closed: PID feedback level is too low.
114
3F PID feedback high
All Modes
Closed: The PID feedback level is too high.
114
4A During KEB Ride-Thru
All Modes
Closed: KEB Ride-Thru is being performed.
114
4C During fast stop
All Modes
Closed: A Fast Stop command has been entered from the operator or input terminals.
114
4D oH Pre-alarm time limit
All Modes
Closed: oH pre-alarm time limit has passed.
114
60 Internal cooling fan alarm
All Modes
Closed: Internal cooling fan alarm
114
90 to 92
DriveWorksEZ
digital outputs 1 to 3
All Modes
Reserved for DWEZ digital output functions.
114
100 to 192
Function 0 to 92 with inverse
output
All Modes
Inverts the output switching of the multi-function output functions.
Set the last two digits of 1oo to reverse the output signal of that specific function.
114
u
H3: Multi-Function Analog Inputs
No.
(Addr.
Hex)
Name Description Values Page
H3-01
(410)
Terminal A1 Signal Level
Selection
All Modes
0: 0 to 10 V
1: -10 to 10 V
Default: 0
Range: 0, 1
115
H3-02
(434)
Terminal A1 Function
Selection
All Modes
Sets the function of terminal A1.
Default: 0
Range: 0 to 31
115
H3-03
(411)
Terminal A1 Gain Setting
All Modes
Sets the level of the input value selected in H3-02 when 10 V is input at
terminal A1.
Default: 100.0%
Min.: -999.9
Max.: 999.9
115
H3-04
(412)
Terminal A1 Bias Setting
All Modes
Sets the level of the input value selected in H3-02 when 0 V is input at terminal
A1.
Default: 0.0%
Min.: -999.9
Max.: 999.9
115
H3-05
(413)
Terminal A3 Signal Level
Selection
All Modes
0: 0 to 10 V
1: -10 to 10 V
Default: 0
Range: 0, 1
116
H3-06
(414)
Terminal A3 Function
Selection
All Modes
Sets the function of terminal A3.
Default: 2
Range: 0 to 31
116
H3-07
(415)
Terminal A3 Gain Setting
All Modes
Sets the level of the input value selected in H3-06 when 10 V is input at
terminal A3.
Default: 100.0%
Min.: -999.9
Max.: 999.9
117
H3-08
(416)
Terminal A3 Bias Setting
All Modes
Sets the level of the input value selected in H3-06 when 0 V is input at terminal
A3.
Default: 0.0%
Min.: -999.9
Max.: 999.9
117
A.9 H Parameters: Multi-Function Terminals
276
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual

YASKAWA A1000 HHP Specifications

General

Series	A1000
Overload Capacity	150% for 60 seconds
Horsepower	0.5-1000 HP
Control Method	V/f Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Ground Fault
Communication	Modbus, DeviceNet, Profibus, Ethernet/IP
Input Voltage	200-240 V, 380-480 V
Output Voltage	0-Input Voltage
Frequency	400 Hz
Power Range	0.4-630 kW
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% RH (non-condensing)
Enclosure Rating	IP20, IP00
Voltage	200-480 V
