A.8 F: Options
F parameters program the drive for PG feedback from the motor and to function with option cards.
u
F1: PG Speed Control Card (PG-X3/PG-B3)
Parameters F1-01, F1-05, F1-06, F1-12, F1-20, F1-21 include “PG 1” in the parameter name and are used to set up a PG option
card plugged into option port CN5-C of the drive.
Parameters F1-21 through F1-37 include “PG 2” in the parameter name and are used to set up a PG option card plugged into
option port CN5-B of the drive.
Other parameters in the F1 group are used to set operation for PG options plugged into port CN5-C and CN5-B.
No.
(Addr.
Hex)
Name Description Values Page
F1-01
(380)
PG 1 Pulses Per Revolution
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
Sets the number of PG (pulse generator or encoder) pulses. Sets the number
of pulses per motor revolution.
Default: 1024 ppr
Min.: 1
Max.: 60000
84
F1-02
(381)
Operation Selection at PG
Open Circuit (PGo)
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
0: Ramp to stop. Decelerate to stop using the deceleration time in C1-02.
1: Coast to stop.
2: Fast Stop. Decelerate to stop using the deceleration time in C1-09.
3: Alarm only.
4: No alarm display
Note: Due to potential damage to the motor and machinery, only use
the “Alarm only” and “No alarm display” settings under special
circumstances.
Default: 1
Range: 0 to 4
84
F1-03
(382)
Operation Selection at
Overspeed (oS)
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
0: Ramp to stop. Decelerate to stop using the deceleration time in C1-02.
1: Coast to stop.
2: Fast Stop. Decelerate to stop using the deceleration time in C1-09.
3: Alarm only.
Default: 1
Range: 0 to 3
84
F1-04
(383)
Operation Selection at
Deviation
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLV
0: Ramp to stop. Decelerate to stop using the deceleration time in C1-02.
1: Coast to stop.
2: Fast Stop. Decelerate to stop using the deceleration time in C1-09.
3: Alarm only.
Default: 3
Range: 0 to 3
85
F1-05
(384)
PG 1 Rotation Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
0: Pulse A leads
1: Pulse B leads
Default:
<1>
Range: 0, 1
85
F1-06
(385)
PG 1 Division Rate for PG
Pulse Monitor
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
Sets the division ratio for the pulse monitor used of the PG option card installed
to port CN5-C.
By setting “xyz”, the division ratio becomes = [(1 + x) / yz].
If only using the A pulse for one-track input, the input ratio will be 1:1
regardless of F1-06 setting.
Default: 1
Min.: 1
Max.: 132
85
F1-08
(387)
Overspeed Detection Level
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLV
Sets the overspeed detection level as a percentage of the maximum output
frequency.
Default: 115%
Min.: 0
Max.: 120
84
F1-09
(388)
Overspeed Detection Delay
Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLV
Sets the time in seconds for an overspeed situation to trigger a fault (oS).
Default:
<1>
Min.: 0.0 s
Max.: 2.0 s
84
A.8 F: Options
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
261
