No.
(Addr.
Hex)
Name Description Values Page
F1-10
(389)
Excessive Speed Deviation
Detection Level
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLV
Sets the speed deviation detection level as a percentage of the maximum output
frequency.
Default: 10%
Min.: 0
Max.: 50
85
F1-11
(38A)
Excessive Speed Deviation
Detection Delay Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
AOLV/PM CLV/PM
CLV
Sets the time in seconds for a speed deviation situation to trigger a fault (dEv).
Default: 0.5 s
Min.: 0.0
Max.: 10.0
85
F1-12
(38B)
PG 1 Gear Teeth 1
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
Sets the gear ratio between the motor shaft and the encoder (PG).
A gear ratio of 1 will be used if F1-12 or F1-13 are set to 0.
Default: 0
Min.: 0
Max.: 1000
85
F1-13
(38C)
PG 1 Gear Teeth 2
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
Sets the gear ratio between the motor shaft and the encoder (PG). A gear ratio
of 1 will be used if F1-12 or F1-13 are set to 0.
Default: 0
Min.: 0
Max.: 1000
85
F1-14
(38D)
PG Open-Circuit Detection
Time
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
Sets the time required to trigger a PG Open fault (PGo).
Default: 2.0 s
Min.: 0.0
Max.: 10.0
84
F1-20
(3B4)
PG Option Card Disconnect
Detection 1
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
CLV/PM
CLV
0: Disabled
1: Enabled
Default: 1
Range: 0, 1
86
F1-21
(3BC)
PG 1 Signal Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
0: A pulse detection
1: AB pulse detection
Default: 0
Range: 0, 1
86
F1-30
(3AA)
PG Card Option Port for
Motor 2 Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLV
Sets the port for the PG option card used by motor 2.
0: CN5-C
1: CN5-B
Default: 1
Range: 0, 1
86
F1-31
(3B0)
PG 2 Pulses Per Revolution
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLV
Sets the number of pulses for a PG option card connected to port CN5-B.
Default: 1024 ppr
Min.: 1
Max.: 60000
84
F1-32
(3B1)
PG 2 Rotation Selection
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLV
0: Pulse A leads
1: Pulse B leads
Default: 0
Range: 0, 1
85
F1-33
(3B2)
PG 2 Gear Teeth 1
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
Sets the gear ratio between the motor shaft and the encoder (PG).
A gear ratio of 1 will be used if F1-33 or F1-34 are set to 0.
Default: 0
Min.: 0
Max.: 1000
85
F1-34
(3B3)
PG 2 Gear Teeth 2
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG
Sets the gear ratio between the motor shaft and the encoder (PG). A gear ratio
of 1 will be used if F1-33 or F1-34 are set to 0.
Default: 0
Min.: 0
Max.: 1000
85
F1-35
(3BE)
PG 2 Division Rate for Pulse
Monitor
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLV
Sets the division ratio for the pulse monitor used of the PG option card 2
installed to port CN5-B.
By setting “xyz”, the division ratio becomes = [(1 + x) / yz].
Default: 1
Min.: 1
Max.: 132
85
F1-36
(3B5)
PG Option Card Disconnect
Detection 2
V/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLVV/f
OLV/PM
V/f w PG
AOLV/PM
OLV
CLV/PM
CLVV/f w PG CLV
0: Disabled
1: Enabled
Default: 1
Range: 0, 1
86
A.8 F: Options
262
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
