Table A.8 YEC 690 V Class Drives Default Settings by Drive Model Selection and ND/HD Settings
Constant
No.
Name Unit
Default Settings
Note: 690 V class default values when o2-o9 = 0
– Model Type 6300 6600 6900 6C00 6F00
C6-01 ND/HD Select – HD ND HD ND HD ND HD ND HD ND
o2-04 Drive Model Selection –
241
(F1H)
241
(F1H)
242
(F2H)
242
(F2H)
243
(F3H)
243
(F3H)
244
(F4H)
244
(F4H)
245
(F5H)
245
(F5H)
Inverter Rated Current A 360.0 414.0 700.0 800.0 1050.0 1200.0 1400.0 1600.0 1750.0 2000.0
E2-11
(E4-11)
Motor Rated Power KW 300.0 335.0 600.0 670.0 900.0 1005.0 1200.0 1340.0 1500.0 1675.0
b3-04 V/f Gain during Speed Search % 80 80 80 80 80 80 80 80 80 80
b3-06
Output Current 1 during
Speed Search
– 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
E2-01
(E4-01)
Motor Rated Current A 350.0 350.0 700.0 700.0 1050.0 1050.0 1400.0 1400.0 1750.0 1750.0
E2-02
(E4-02)
Motor Rated Slip Hz 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
E2-03
(E4-03)
Motor No-Load Current A 70.0 70.0 140.0 140.0 210.0 210.0 280.0 280.0 350.0 350.0
E2-05
(E4-05)
Motor Line-to-Line
Resistance
mΩ 14.000 14.000 10.000 10.000 8.000 8.000 7.000 7.000 6.000 6.000
E2-06
(E4-06)
Motor Leakage Inductance % 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0
E2-10
(E4-10)
Motor Iron Loss for Torque
Compensation
W 0 0 0 0 0 0 0 0 0 0
L2-02
Momentary Power Loss Ride-
Through Time
s 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-03
Momentary Power Loss
Minimum Baseblk Time
s 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-04
Momentary Power Loss
Voltage Recovery Time
s 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
L8-02 Overheat Alarm Level °C 130 130 130 130 130 130 130 130 130 130
L8-38
Carrier Frequency Reduction
Selection
– 2 2 2 2 2 2 2 2 2 2
A.18 Defaults by Drive Model and Duty Rating ND/HD
