Register No. Contents
004BH
Drive status (U1-12)
bit 0 During Run
bit 1 During Zero Speed
bit 2 During Reverse Run
bit 3 During Fault Reset Signal Input
bit 4 During Speed Agree
bit 5 Drive Ready
bit 6 Alarm
bit 7 Fault
bit 8
During Operation Error (oPEoo)
bit 9 During Momentary Power Loss
bit A Motor 2 selected
bit B Reserved
bit E ComRef status, NetRef status
bit F ComCtrl status, NetCtrl status
004CH to 007EH
Used for various monitors U1-oo, U4-oo, U5-oo and U6-oo. Refer to U: Monitors on page 298 for parameter details.
007FH Alarm Code, Refer to Alarm Register Contents on page 343 for alarm codes.
0080H to 0097H
Used for monitors U2-oo, U3-oo. Refer to U: Monitors on page 298 for parameter details and Refer to Fault Trace
Contents on page 341 for register value descriptions.
0098H High Word of Accumulated Operation Time Monitor, 10 h units (U4-01)
0099H Low Word of Accumulated Operation Time Monitor, 1 h units (U4-01)
009AH High Word of Cooling Fan Operation Time Monitor (U4-03)
009BH Low Word of Cooling Fan Operation Time Monitor (U4-03)
009CH to 00AAH Reserved
00ABH
Drive Rated Current
<2>
00ACH
Motor Speed (U1-05)
r/min units
<4>
00ADH 0.01% units
00AEH, 00AFH Reserved
00B0H
Option Code Connected to
CN5-A
Register contains ASCII code of the option card.
DI-A3 = 0x01
DO-A3 = 0x02
AI-A3 = 0x03
AO-A3 = 0x04
PG-B3 = 0x11
PG-X3 = 0x12
Communication Option: Register contains ASCII code of 1st and 3rd digit of the option card type
number.
Example: Register value is 5343H for “SC” if a SI-C3 option card is installed.
00B1H Reserved
00B2H Option Code Connected to CN5-B
00B3H Option Code Connected to CN5-C
00B4H Reserved
00B5H
Frequency Reference After
Soft-starter (U1-16)
r/min units
<4>
00B6H 0.01% units
00B7H
Frequency Reference
r/min
<4>
00B8H 0.01% units
00B9H to 00BEH Reserved
00BFH
Lists the last two digits of operation error code oPEoo.
B.9 MEMOBUS/Modbus Data Table
332
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
