YASKAWA A1000 HHP

Register No. Contents
00CBH
Alarm Contents 5
bit 0 SI-T3 Watchdog Error (E5)
bit 1 SI-T3 Station Address Setting Error (AEr)
bit 2 SI-T3 Comm. Cycle Setting Error (CyC)
bit 3 High Current Alarm (HCA)
bit 4 Cooling Fan Maintenance Time (LT-1)
bit 5 Soft Charge Bypass Relay Maintenance Time (LT-2)
bit 6 Reserved
bit 7 SI-S EEPROM Error (EEP)
bit 8 External Fault 1 (input terminal S1) (EF1)
bit 9 External Fault 2 (input terminal S2) (EF2)
bit A
Safe Disable Input (HbbF)
<5>
bit B
Safe Disable Input (Hbb)
<5>
bit C Mechanical Weakening Detection 1 (oL5)
bit D Mechanical Weakening Detection 2 (UL5)
bit E, F Reserved
00CCH
Alarm Contents 6
bit 0 Output Voltage Detection Fault (VoF)
bit 1 IGBT Maintenance Time (90%) (TrPC)
bit 2 Capacitor Maintenance Time (LT-3)
bit 3 IGBT Maintenance Time (50%) (LT-4)
bit 4 Unused
bit 5 to 7 Reserved
bit 8 DriveWorksEZ Alarm (dWAL)
bit 9 to F Reserved
00CDH
bit 0 to 7 Reserved
bit 8 EFAn (Abnormal Fan Alarm)
bit 9 Reserved
bit A dFAn (Abnormal Fan Diode Module)
bit B to F Reserved
00CEH-00CFH Reserved
00D0H
CPF Contents 1
bit 0, 1 Reserved
bit 2 A/D Conversion Error (CPF02)
bit 3 PWM Data Fault (CPF03)
bit 4, 5 Reserved
bit 6 EEPROM Memory Data Error (CPF06)
bit 7 Terminal Board Connection Error (CPF07)
bit 8 EEPROM Serial Communications Fault (CPF08)
bit 9, A Reserved
bit B RAM Fault (CPF11)
bit C FLASH Memory Fault (CPF12)
bit D Watchdog Circuit Exception (CPF13)
bit E Control Circuit Fault (CPF14)
bit F Reserved
B.9 MEMOBUS/Modbus Data Table
336
