YASKAWA A1000 HHP User Manual

Fault Code Fault Name
00A9H Control Circuit Error (CPF40)
00AAH Control Circuit Error (CPF41)
00ABH Control Circuit Error (CPF42)
00ACH Control Circuit Error (CPF43)
00ADH Control Circuit Error (CPF44)
00AEH Control Circuit Error (CPF45)
0101H Option Compatibility Error (oFA00)
0102H Option Not Properly Connected (oFA01)
0103H
Same Type of Option Card Already Connected
(oFA02)
0106H A/D Conversion Error (oFA05)
0107H Option Response Error (oFA06)
0111H Option RAM Fault (oFA10)
0112H Option Operation Mode Fault (SLMOD) (oFA11)
0113H Drive Receive CRC Error (oFA12)
0114H Drive Receive Frame Error (oFA13)
0115H Drive Receive Abort Error (oFA14)
0116H Option Receive CRC Error (oFA15)
0117H Option Receive Frame Error (oFA16)
0118H Option Receive Abort Error (oFA17)
0131H Comm. ID Error (oFA30)
0132H Model Code Error (oFA31)
0133H Sumcheck Error (oFA32)
0134H
Comm. Option Timeout Waiting for Response
(oFA33)
0135H MEMOBUS Timeout (oFA34)
0136H Drive Timeout Waiting for Response (oFA35)
0137H CI Check Error (oFA36)
0138H Drive Timeout Waiting for Response (oFA37)
0139H Control Command Selection Error (oFA38)
013AH Drive Timeout Waiting for Response (oFA39)
013BH Control Response Selection 1 Error (oFA40)
013CH Drive Timeout Waiting for Response (oFA41)
013DH Control Response Selection 2 Error (oFA42)
Fault Code Fault Name
013EH Control Response Selection Error (oFA43)
0201H Option Connection Error (oFb01)
0202H
Same Type of Option Card Already Connected
(oFb02)
0205H A/D Conversion Error (oFb05)
0206H Option Response Error (oFb06)
0210H Option RAM Fault (oFb10)
0211H Option Operation Mode Fault (SLMOD) (oFb11)
0212H Drive Receive CRC Error (oFb12)
0213H Drive Receive Frame Error (oFb13)
0214H Drive Receive Abort Error (oFb14)
0215H Option Receive CRC Error (oFb15)
0216H Option Receive Frame Error (oFb16)
0217H Option Receive Abort Error (oFb17)
0231H Comm. ID Error (oFb30)
0232H Model Code Error (oFb31)
0233H Sumcheck Error (oFb32)
0234H Comm. option Timeout Waiting for Response (oFb33)
0235H MEMOBUS Timeout (oFb34)
0236H Drive Timeout Waiting for Response (oFb35)
0237H CI Check Error (oFb36)
0238H Drive Timeout Waiting for Response (oFb37)
0239H Control Command Selection Error (oFb38)
023AH Drive Timeout Waiting for Response (oFb39)
023BH Control Response Selection 1 Error (oFb40)
023CH Drive Timeout Waiting for Response (oFb41)
023DH Control Response Selection 2 Error (oFb42)
023EH Control Response Selection Error (oFb43)
0300H Option Compatibility Error (oFC00)
0301H Option Not Properly Connected (oFC01)
0302H
Same Type of Option Card Already Connected
(oFC02)
0305H A/D Conversion Error (oFC05)
0306H Option Response Error (oFC06)
B.9 MEMOBUS/Modbus Data Table
342
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual

YASKAWA A1000 HHP Specifications

General

Series	A1000
Overload Capacity	150% for 60 seconds
Horsepower	0.5-1000 HP
Control Method	V/f Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Ground Fault
Communication	Modbus, DeviceNet, Profibus, Ethernet/IP
Input Voltage	200-240 V, 380-480 V
Output Voltage	0-Input Voltage
Frequency	400 Hz
Power Range	0.4-630 kW
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% RH (non-condensing)
Enclosure Rating	IP20, IP00
Voltage	200-480 V
