10.5 I/O Signal Cables for SERVOPACKs
10.5.2 For Σ-7S MECHATROLINK-II/-III Communications Reference or Command Option Attachable-Type SERVOPACKs
10-18
Connector Kits
Selection Table
• Wire Sizes
Note: Use a twisted-pair or screened twisted-pair cable.
Dimensional Drawings
Case
Connectors
Connector Kit
Order Number
Case Connectors
Model Qty Model Qty
JZSP-CSI9-2-E
10326-52A0-008
(3M Japan Limited)
1 set
10126-3000PE (soldered)
(3M Japan Limited)
1
Item Specification
Applicable Wires AWG24, 26, 28, 30
Cable Finished Diameter 16 mm max.
37.2
12.7
25.8
31.3
12.0
14.0
39.0
23.8
(5.2)
10.0
Unit: mm
2.54
1.27
21.5
15.24
15°
1.27
25.8
5.1
(6.8)
19.5
(2.9)
2.3
12.7
3M
9.1
7.5
Unit: mm
Pin 14
Pin 1
Pin 13
Pin 12
Pin 2Pin 1
Pin 15
Pin 26
Pin 14
Pin 25
