YASKAWA SGD7W - Option Modules

10.1 System Configuration Diagrams and Selection Tables
10.1.1 Cable Configurations
10
Cables and User-Assembled Wiring Materials for SERVOPACKs
10-5
 Σ-7S (Single Axis) Command Option
Attachable-Type SERVOPACKs
 Option Module: Safety Module
 Command Option Module: INDEXER Module  Command Option Module: DeviceNet Module
Analog Monitor Cable
CN5
Digital Operator
Conversion Cable
Safety Function
Device Cable




I/O Signal Cable
To external devices,
such as LED indicators
CN1
CN3
CN7
CN8
Digital
Operator
Computer Cable
JZSP-CVS06-02-E
CN21
Safety Function Device Cable
CN22

CN11
CN12
I/O Signal Cable
Serial Command Cable
Host controller
(DeviceNet device)
DeviceNet
Communications Cable
CN6
