6.3 User-Assembled Wiring Materials for Servomotor Main Circuit Cables
6.3.4 IP67-Structure/European-Safety-Standard-Compliant Servomotor Connectors for 850 W to 15 kW
6-16
6.3.4
IP67-Structure/European-Safety-Standard-Compliant
Servomotor Connectors for 850 W to 15 kW
Cables with connectors on both ends that are compliant with an IP67 protective structure and
European Safety Standards are not available from Yaskawa for SGM7G Servomotors. You must
make such a cable yourself.
Use the Connectors specified by Yaskawa for these Servomotors. (These connectors are com-
pliant with the standards.) Yaskawa does not specify what wiring materials to use.
Connector Structures
Note: For the conduit grounding, contact the manufacturer of the conduit.
For Servomotors without Holding Brakes
Servomo-
tor Model
Capacity
Servomotor
Connector
Model
(Recepta-
cle)
Order Number
Applica-
ble
Cable
Diame-
ter (Ref-
erence
Values)
[mm]
Manu-
facturer
Plug
Only
Straight
Plug
Right-Angle
Plug
Cable Clamp
SGM7G-09
SGM7G-13
SGM7G-20
850 W to
1.8 kW
CE05-2A18
-10PD-D
CE05-
6A18-
10SD-
D
CE05-
6A18-
10SD-D-
BSS
CE05-
8A18-
10SD-D-
BAS
CE3057
-10A-1-D
10.5 to
14.1
DDK
Ltd.
CE3057
-10A-2-D
8.5 to
11.0
CE3057
-10A-3-D
6.5 to
8.7
SGM7G-30
SGM7G-44
2.9 kW to
4.4 kW
CE05-2A22
-22PD-D
CE05-
6A22-
22SD-
D
CE05-
6A22-
22SD-D-
BSS
CE05-
8A22-
22SD-D-
BAS
CE3057
-12A-1-D
12.5 to
16.0
CE3057
-12A-2-D
9.5 to
13.0
CE3057
-12A-3-D
6.8 to
10.0
CE3057
-12A-7-D
14.5 to
17.0
SGM7G-55
SGM7G-75
SGM7G-1A
SGM7G-1E
5.5 kW to
15 kW
CE05-2A32
-17PD-D
CE05-
6A32-
17SD-
D
CE05-
6A32-
17SD-D-
BSS
CE05-
8A32-
17SD-D-
BAS
CE3057
-20A-1-D
22 to
23.8
CE3057
-20A-2-D
24 to
26.6
CE3057
-20A-3-D
22 to
22.5
Plug
Conduit
Servomotor Connector
(receptacle)
Cable Clamp
(waterproof)
Cable
Cable
Straight Plug
(waterproof)
Right-Angle Plug
(waterproof)
