4.2 Servomotor Main Circuit Cables
4.2.2 Servomotor Main Circuit Cables for Servomotors with Holding Brakes
4
Cables and User-Assembled Wiring Materials for SGM7A Rotary Servomotors
4-7
4.2.2 Servomotor Main Circuit Cables for Servomotors with
Holding Brakes
Selection Table
 SGM7A-A5 to -10 (50 W to 1.0 kW)
*1. Replace the boxes () in the order number with the cable length (03, 05, 10, 15, 20, 30, 40, or 50).
*2. Use Flexible Cables for moving parts of machines, such as robots.
*3. The recommended bending radius (R) is 90 mm or larger.
Note: If the length of the Servomotor Main Circuit Cable exceeds 20 m, the intermittent duty zone in the torque-
motor speed characteristics will become smaller because the voltage drop increases.
 SGM7A-15 to -50 (1.5 kW to 5.0 kW)
*1. Replace the boxes () in the order number with the cable length (03, 05, 10, 15, or 20).
*2. Use Flexible Cables for moving parts of machines, such as robots.
*3. The recommended bending radius (R) is 90 mm or larger.
Cable
Direction
Servomotor
Model
Length (L)
Order Number
*1
Standard Cable Flexible Cable
*2, *3
Load side
SGM7A-A5 to -C2
50 W to 150 W
3 m, 5 m, 10 m, 15 m,
20 m, 30 m, 40 m, and
50 m
JZSP-C7M13F-
-E JZSP-C7M14F--E
SGM7A-02 to -06
200 W to 600 W
JZSP-C7M23F-
-E JZSP-C7M24F--E
SGM7A-08 or -10
750 W or 1.0 kW
JZSP-C7M33F-
-E JZSP-C7M34F--E
Non-load
side
SGM7A-A5 to -C2
50 W to 150 W
JZSP-C7M13G-
-E JZSP-C7M14G--E
SGM7A-02 to -06
200 W to 600 W
JZSP-C7M23G-
-E JZSP-C7M24G--E
SGM7A-08 or -10
750 W or 1.0 kW
JZSP-C7M33G-
-E JZSP-C7M34G--E
Servomotor
Model
Connector
Specifications
Length (L)
Order Number
*1
Set of Two Cables
(Main Power Supply Cable and Holding
Brake Cable)
Standard Cable Flexible Cable
*2, *3
SGM7A-15
1.5 kW
Straight
3 m, 5 m, 10 m, 15 m,
and 20 m
JZSP-UVA131-
-E JZSP-UVA141--E
Right-angle JZSP-UVA132--E JZSP-UVA142--E
SGM7A-20
2.0 kW
Straight JZSP-UVA331-
-E JZSP-UVA341--E
Right-angle JZSP-UVA332--E JZSP-UVA342--E
SGM7A-25
2.5 kW
Straight JZSP-U7A551-
-E JZSP-U7A561--E
Right-angle JZSP-U7A552-
-E JZSP-U7A562--E
SGM7A-30
3.0 kW
Straight JZSP-UVA631-
-E JZSP-UVA641--E
Right-angle JZSP-UVA632--E JZSP-UVA642--E
SGM7A-40 or -50
4.0 kW or 5.0 kW
Straight JZSP-UVA731-
-E JZSP-UVA741--E
Right-angle JZSP-UVA732--E JZSP-UVA742--E
