YASKAWA SGD7W - Selection Table

10.1 System Configuration Diagrams and Selection Tables
10.1.2 Selection Table
10
Cables and User-Assembled Wiring Materials for SERVOPACKs
10-7

I/O Signal
Cables
Soldered Connector Kit DP9420007-E
Connector-
Terminal
Block Con-
verter Unit
(with cable)
0.5 m JUSP-TA36P-E
1 m JUSP-TA36P-1-E
2 m JUSP-TA36P-2-E
Cable with
Loose Wires
at One End
(loose wires
on peripheral
device end)
1 m JZSP-CSI03-1-E
2 m JZSP-CSI03-2-E
3 m JZSP-CSI03-3-E

Safety
Function
Device
Cable
Cables with
Connectors
*3
1 m JZSP-CVH03-01-E
3 m JZSP-CVH03-03-E
Connector Kit
*4
Contact Tyco Electronics Japan G.K.
Product name: Industrial Mini I/O D-shape Type 1 Plug Con-
nector Kit
Model number: 2013595-1

MECHATRO
LINK-II
Communi-
cations
Cables
Cables with
Connectors
on Both Ends
0.5 m JEPMC-W6002-A5-E
1 m JEPMC-W6002-01-E
3 m JEPMC-W6002-03-E
5 m JEPMC-W6002-05-E
10 m JEPMC-W6002-10-E
20 m JEPMC-W6002-20-E
30 m JEPMC-W6002-30-E
40 m JEPMC-W6002-40-E
50 m JEPMC-W6002-50-E
Cables with
Connectors
on Both Ends
(with ferrite
cores)
0.5 m JEPMC-W6003-A5-E
1 m JEPMC-W6003-01-E
3 m JEPMC-W6003-03-E
5 m JEPMC-W6003-05-E
10 m JEPMC-W6003-10-E
20 m JEPMC-W6003-20-E
30 m JEPMC-W6003-30-E
40 m JEPMC-W6003-40-E
50 m JEPMC-W6003-50-E
Terminators JEPMC-W6022-E
Continued on next page.
Continued from previous page.
Code Name
Length
(L)
Order Number Appearance
40
39
1
2
B20
A20
B1
A1
L
L
L
L
L
