YASKAWA SGD7W - Page 253

10.10 I/O Signal Cables for INDEXER Modules
10.10.2 Connector Kits
10-35
10
Cables and User-Assembled Wiring Materials for SERVOPACKs
Dimensional Drawings
 Connector
 Case
2.54
Pin 19
1.27
Pin 19
Pin 1
27.8
21.59
15°
1.27
32.2
5.1
(6.8)
19.5
(2.9)
2.3
12.7
Pin 20
Pin 1
Pin 2
Pin 17
Pin 18
Pin 36
Pin 35
9.1
7.5
Unit: mm
43.5
12.7
32.2
37.6
17.0
14.0
39.0
23.8
(5.2)
14.0
Unit: mm
