5.1 Cable Configurations
5
Cables and User-Assembled Wiring Materials for SGM7P Rotary Servomotors
5-3
*1. If a battery is connected to the host controller, the Battery Case is not required. Use an Encoder Cable for Incre-
mental Encoders or Batteryless Absolute Encoders.
*2. This Cable is not required if you use a Servomotor with an Incremental Encoder, use a Servomotor with a Bat-
teryless Absolute Encoder, or connect a battery to the host controller.
To Next Page
