o1-06: User Monitor Selection Mode
Normally the monitors shown directly below the active monitor are the next two sequential monitors. If o1-06 (User Monitor
Selection Mode) is set to 1: “3 Mon Selectable”, those two monitors are locked as specified by parameters o1-07 and o1-08
and will not change as the top parameter is scrolled with the Up/Down Arrow keys.
No. Name Setting Range Default
o1-06 User Monitor Selection Mode 0, 1 0
Setting 0: 3 Monitor Sequential (Displays the Next 2 Sequential Monitors)
Setting 1: 3 Monitor Selectable (o1-07, and o1-08 Selected Monitor Is Shown)
n
o1-07: Second Line Monitor Selection
Selects which monitor will be displayed in the second line. The monitor parameter number is entered into the spaces provided:
Uo-oo.
For example, set “403” to display monitor parameter U4-03.
No. Name Setting Range Default
o1-07 Second Line Monitor Selection 101 to 699 102
n
o1-08: Third Line Monitor Selection
Selects which monitor will be displayed in the third line. The monitor parameter number is entered into the spaces provided:
Uo-oo.
For example, set “403” to display monitor parameter U4-03.
No. Name Setting Range Default
o1-08 Third Line Monitor Selection 101 to 699 103
n
o1-09: Frequency Reference Display Units
Sets unit display for the frequency reference parameters and frequency related monitors when o1-03 = 3.
No. Name Setting Range Default
o1-09 Frequency Reference Display Units 0 to 16 16
Setting 0: Inch of Water (“WC)
Setting 1: Pounds per Square Inch (PSI)
Setting 2: Gallons per Minute (GPM)
Setting 3: Degrees Fahrenheit (F)
Setting 4: Cubic Feet per Minute (CFM)
Setting 5: Cubic Meters per Hour (CMH)
Setting 6: Liters per Hour (LPH)
Setting 7: Liters per Second (LPS)
Setting 8: Bar (Bar)
Setting 9: Pascals (Pa)
Setting 10: Degrees Celsius (C)
Setting 11: Meters (Mtr)
Setting 12: Ft (Feet)
Setting 13: Liters per Minute (LPM)
Setting 14: Cubic Meters per Minute (CMM) No unit
Setting 15: Custom Units (Determined by o1-12)
Setting 16: None
n
o1-10: User-Set Display Units Maximum Value
Determines the display value that is equal to the maximum output frequency.
1.10 o: Operator-Related Settings
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
129
1
Parameter Details
