Register No. Contents
00D9H
oFA1o Contents (CN5)
bit 0 Option RAM Fault (oFA10)
bit 1 Option Operation Mode Fault (SLMoD) (oFA11)
bit 2 Drive Receive CRC Error (oFA12)
bit 3 Drive Receive Frame Error (oFA13)
bit 4 Drive Receive Abort Error (oFA14)
bit 5 Option Receive CRC Error (oFA15)
bit 6 Option Receive Frame Error (oFA16)
bit 7 Option Receive Abort Error (oFA17)
bit 8 to F Reserved
00DAH Reserved
00DBH
oFA3o Contents (CN5)
bit 0 Comm. ID Error (oFA30)
bit 1 Model Code Error (oFA31)
bit 2 Sumcheck Error (oFA32)
bit 3 Comm. option timeout waiting for response (oFA33)
bit 4 MEMOBUS Timeout (oFA34)
bit 5 Drive timeout waiting for response (oFA35)
bit 6 CI Check Error (oFA36)
bit 7 Drive timeout waiting for response (oFA37)
bit 8 Control Command Selection Error (oFA38)
bit 9 Drive timeout waiting for response (oFA39)
bit A Control Response Selection 1 Error (oFA40)
bit B Drive timeout waiting for response (oFA41)
bit C Control Response Selection 2 Error (oFA42)
bit D Control Response Selection Error (oFA43)
bit E, bit F Reserved
00DCH to 00E9H Reserved
00EAH
Fault Contents 9
bit 0 Time Not Set (TIM)
bit 1 Oper Battery Low (bAT)
bit 2 Time Data Err (TdE)
bit 3 Time Interval Error (TIE)
bit 4 Overvoltage 2 (ov2)
bit 5 Reserved
bit 6 External Fan Fault (Fn1)
bit 7 to F Reserved
00EBH to 00FFH Reserved
0100H to 2FFFH Reserved
3000H to 3003H
Used for Various Monitors U5-oo. Refer to U: Monitors on page 232 for details.
3004H Set Time HHMM
3005H Set Date Year
3006H Set Date Month Day MMDD
3007H Set RTC
3008H to 3028H
Used for Various Monitors U2-oo, U3-oo, U5-oo. Refer to U: Monitors on page 232 for details.
3029H to 302EH Reserved
302FH RTC Enter
3030H RTC Enter Enable
<1> Parameter o1-03, HOA Keypad Display Selection, determines the units.
<2> Communication error contents are saved until the fault is reset.
E.9 MEMOBUS/Modbus Data Table
324
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
