16-18
IM 765501-01E
:SOURce:VOLTage:PROTection:LLIMit
Function Sets the lower voltage limiter value (for
generating current) or queries the current
setting.
Syntax :SOURce:VOLTage:PROTection:LLIMit
<Voltage>|MINimum|MAXimum
<Voltage> = Sets the limiter value to the
specified value.
MINimum = Sets the limiter value to the
minimum value.
MAXimum = Sets the limiter value to the
maximum value.
:SOURce:VOLTage:PROTection:LLIMit?
[MINimum|MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Voltage>
Example :SOUR:VOLT:PROT:LLIM -25.0
:SOUR:VOLT:PROT:LLIM MIN
:SOUR:VOLT:PROT:LLIM?
:SOUR:VOLT:PROT:LLIM? MIN
Description Note that the voltage limiter is activated when
the source function is set to current
(:SOURce:FUNCtion CURRent).
:SOURce:VOLTage:SWEep:SPACing
Function Sets the sweep mode (linear or log) or queries
the current setting.
Syntax :SOURce:VOLTage:SWEep:SPACing
LINear|LOGarithmic
LINear = Sets the sweep mode to linear.
LOGarithmic = Sets the sweep mode to
logarithmic.
:SOURce:VOLTage:SWEep:SPACing?
→ LIN = Currently set to linear
LOG = Currently set to logarithmic
Example :SOUR:VOLT:SWE:SPAC LIN
:SOUR:VOLT:SWE:SPAC?
Description This setting is used when the source pattern is
set to sweep (:SOURce:MODE SWEep). This
command and :SOURce:CURRent:SWEep:
SPACing are equivalent.
:SOURce:VOLTage:SWEep:STARt
Function Sets the start value of the voltage sweep or
queries the current setting.
Syntax :SOURce:VOLTage:SWEep:STARt
<Voltage>|MINimum|MAXimum
<Voltage> = Sets the start value to the specified
value.
MINimum = Sets the start value to the minimum
value.
MAXimum = Sets the start value to the
maximum value.
:SOURce:VOLTage:SWEep:STARt?
[MINimum|MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Voltage>
Example :SOUR:VOLT:SWE:STAR 0.05
:SOUR:VOLT:SWE:STAR MIN
:SOUR:VOLT:SWE:STAR?
:SOUR:VOLT:SWE:STAR? MIN
:SOURce:VOLTage:SWEep:STOP
Function Sets the stop value of the voltage sweep or
queries the current setting.
Syntax :SOURce:VOLTage:SWEep:STOP
<Voltage>|MINimum|MAXimum
<Voltage> = Sets the stop value to the specified
value.
MINimum = Sets the stop value to the minimum
value.
MAXimum = Sets the stop value to the
maximum value.
:SOURce:VOLTage:SWEep:STOP?
[MINimum|MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Voltage>
Example :SOUR:VOLT:SWE:STOP 12.5
:SOUR:VOLT:SWE:STOP MAX
:SOUR:VOLT:SWE:STOP? MAX
16.2 Commands
