:SOURce:CURRent:RANGe:AUTO
Function Sets the source auto range (ON or OFF) or
queries the current setting.
Syntax :SOURce:CURRent:RANGe:AUTO 1|0|ON|
OFF
1 or ON = Turns auto range ON.
0 or OFF = Turns auto range OFF.
:SOURce:CURRent:RANGe:AUTO?
→ 1 = Currently ON
0 = Currently OFF
Example :SOUR:CURR:RANG:AUTO ON
:SOUR:CURR:RANG:AUTO?
Description This command and :SOURce:VOLTage:
RANGe:AUTO are equivalent.
:SOURce:CURRent:LEVel
Function Sets the current source level value or queries
the current setting.
Syntax :SOURce:CURRent:LEVel <Current>|
MINimum|MAXimum
<Voltage> = Sets the current level to the
specified value.
MINimum = Sets the current level to the
minimum value.
MAXimum = Sets the current level to the
maximum value.
:SOURce:VOLTage:LEVel? [MINimum|
MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Current>
Example :SOUR:CURR:LEV 3.5E-6
:SOUR:CURR:LEV MIN
:SOUR:CURR:LEV?
:SOUR:CURR:LEV? MIN
:SOURce:CURRent:PBASe
Function Sets the pulse base value for current pulse
generation or queries the current setting.
Syntax :SOURce:CURRent:PBASe <Current>|
MINimum|MAXimum
<current> = Sets the pulse base value to the
specified value.
MINimum = Sets the pulse base value to the
minimum value.
MAXimum = Sets the pulse base value to the
maximum value.
:SOURce:CURRent:PBASe? [MINimum|
MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Current>
Example :SOUR:CURR:PBAS -0.5
:SOUR:CURR:PBAS MIN
:SOUR:CURR:PBAS?
:SOUR:CURR:PBAS? MIN
:SOURce:CURRent:PROTection[:STATe]
Function Sets the limiter state (ON or OFF) or queries the
current setting.
Syntax :SOURce:CURRent:PROTection[:STATe]
1|0|ON|OFF
1 or ON = Turns the limiter ON.
0 or OFF = Turns the limiter OFF.
:SOURce:CURRent:PROTection[:STATe]?
→ 1 = Currently ON
0 = Currently OFF
Example :SOUR:CURR:PROT:STAT OFF
:SOUR:CURR:PROT:STAT?
Description This command and :SOURce:VOLTage:
PROTection[:STATe] are equivalent.
:SOURce:CURRent:PROTection:LINKage
Function Sets the limiter tracking state (ON or OFF) or
queries the current setting.
Syntax :SOURce:CURRent:PROTection:LINKage
1|0|ON|OFF
1 or ON = Turns limiter tracking ON.
0 or OFF = Turns limiter tracking OFF.
:SOURce:CURRent:PROTection:LINKage?
→ 1 = Currently ON
0 = Currently OFF
Example :SOUR:CURR:PROT:LINK OFF
:SOUR:CURR:PROT:LINK?
Description This command and :SOURce:VOLTage:
PROTection:LINKage are equivalent.
