:SOURce:CURRent:SWEep:STOP
Function Sets the stop value of the current sweep or
queries the current setting.
Syntax :SOURce:CURRent:SWEep:STOP
<Current>|MINimum|MAXimum
<current> = Sets the stop value to the specified
value.
MINimum = Sets the stop value to the minimum
value.
MAXimum = Sets the stop value to the
maximum value.
:SOURce:CURRent:SWEep:STOP?
[MINimum|MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Current>
Example :SOUR:CURR:SWE:STOP 1.25
:SOUR:CURR:SWE:STOP MAX
:SOUR:CURR:SWE:STOP?
:SOUR:CURR:SWE:STOP? MAX
:SOURce:CURRent:SWEep:STEP
Function Sets the step value of the current sweep (linear
sweep) or queries the current setting.
Syntax :SOURce:CURRent:SWEep:STEP
<Voltage>|MINimum|MAXimum
<current> = Sets the step value to the specified
value.
MINimum = Sets the step value to the minimum
value.
MAXimum = Sets the step value to the
maximum value.
:SOURce:CURRent:SWEep:STEP?
[MINimum|MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Current>
Example :SOUR:CURR:SWE:STEP 1.25
:SOUR:CURR:SWE:STEP MIN
:SOUR:CURR:SWE:STEP?
:SOUR:CURR:SWE:STEP? MIN
Description This setting is used when the sweep mode is
set to linear (:SOURce:VOLTage:SWEep:
SPACing LINear).
:SOURce:CURRent:SWEep:POINts
Function Sets the step count of the current sweep (log
sweep) or queries the current setting.
Syntax :SOURce:CURRent:SWEep:POINts
<Integer>|MINimum|MAXimum
<Integer> = Sets the step count to the specified
value.
MINimum = Sets the step count to the minimum
value.
MAXimum = Sets the step count to the
maximum value.
:SOURce:CURRent:SWEep:POINts?
[MINimum|MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Integer>
Example :SOUR:CURR:SWE:POIN 100
:SOUR:CURR:SWE:POIN MAX
:SOUR:CURR:SWE:POIN?
:SOUR:CURR:SWE:POIN? MAX
Description This setting is used when the sweep mode is
set to logarithmic (:SOURce:CURRent:SWEep:
SPACing LOGarithmic).
:SOURce:CURRent:ZERO:IMPedance
Function Sets the zero source impedance (high or low)
for generating current or queries the current
setting.
Syntax :SOURce:CURRent:ZERO:IMPedance
HIGH|LOW
HIGH = Sets the impedance to high.
LOW = Sets the impedance to low.
:SOURce:CURRent:ZERO:IMPedance?
→ HIGH = Currently set to high impedance
LOW = Currently set to low impedance
Example :SOUR:CURR:ZERO:IMP HIGH
:SOUR:CURR:ZERO:IMP?
:SOURce:CURRent:ZERO:OFFset
Function Sets the zero source offset value for generating
current or queries the current setting.
Syntax :SOURce:CURRent:ZERO:OFFSet
<Current>
<Voltage> = Sets the offset value to the
specified current.
:SOURce:CURRent:ZERO:OFFSet?
→ <Current>
Example :SOUR:CURR:ZERO:OFFS -0.3
:SOUR:CURR:ZERO:OFFS?
