16-32
IM 765501-01E
:ROUTe:BNCO:CONTrol
Function Selects the control output of the BNC output
terminal (interlock, output control, zero control,
or programmable) or queries the current setting.
Syntax :ROUTe:BNCO:CONTrol ILOCk|OUTPut|
ZERO|PROGram
ILOCk = Outputs the interlock state.
OUTPut = Outputs the output state.
ZERO = Outputs the zero state.
PROGram = Sets the control output to
programmable output.
:ROUTe:BNCO:CONTrol?
→ ILOC = Currently set to interlock state
OUTP = Currently set to output state
ZERO = Currently set to zero state
PROG = Currently set to programmable
output
Example :ROUT:BNCO:CONT PROG
:ROUT:BNCO:CONT?
:ROUTe:DIO5
Function Sets the function (output control or zero control)
of pin 5 (control input) of the external input/
output connector or queries the current setting.
Syntax :ROUTe:DIO5 OUTPut|ZERO
OUTPut = Sets the function to output control
input.
ZERO = Sets the function to zero control input.
:ROUTe:DIO5?
→ OUTP = Currently set to output control input
ZERO = Currently set to zero control input
Example :ROUT:DIO5 OUTP
:ROUT:DIO5?
:ROUTe:DIO6
Function Sets the function (trigger start point, source
change, measurement begin, measurement
end, or pulse end) of pin 6 (trigger output) of the
external input/output connector or queries the
current setting.
Syntax :ROUTe:DIO6 ORIGin|SCHange|MBEGin|
MEND|PEND
ORIGin = Sets the function to the trigger point.
SCHange = Sets the function to the source
change point.
MBEGin = Sets the function to measurement
start point.
MEND = Sets the function to measurement end
point.
PEND = Sets the function to pulse end point.
:ROUTe:DIO6?
→ ORIG = Currently set to trigger point
SCH = Currently set to source change point
MBEG = Currently set to measurement start
point
MEND = Currently set to measurement end
point
PEND = Currently set to pulse end point
Example :ROUT:DIO6 MBEG
:ROUT:DIO6?
:ROUTe:DIO7
Function Sets the function (sweep start point, 1 turn end,
or all sweep end) of pin 7 (sweep
synchronization output) of the external input/
output connector or queries the current setting.
Syntax :ROUTe:DIO7 ORIGin|TURN|ALL
ORIGin = Sets the function to the sweep start
point.
TURN = Sets the function to the end of 1 turn.
ALL = Sets the function to the end of all sweeps.
:ROUTe:DIO7?
→ ORIG = Currently set to sweep start
TURN = Currently set to the end of a turn
ALL = Currently set to the end of all sweeps
Example :ROUT:DIO7 END
:ROUT:DIO7?
16.2 Commands
