17-5
IM 765501-01E
Troubleshooting and Maintenance
17
Instrumental Errors (+100 and up)
Error No. Error Message Corrective Action Page
+100 Expression syntax error Check that the syntax of the MATH definition file is correct. App-1
+101 Too complex expression Keep the total number of constants, variables, and operators in a App-1
MATH definition less than or equal to 256.
Keep the total number of constants, variables, and operators in all
MATH definitions less than or equal to 1024.
+201 Interlocking Release the interlock, and then turn the output ON. -
+202 Hardware abnormal Wait for the temperature inside the case to become normal, and -
turn the output ON.
+203 Sweep running Stop the sweep operation before changing the settings. -
+300 Hardware input abnormal error Check the input. -
+301 Low battery Request to have the battery replaced, because the time stamp 17-11
when creating files will not be correct.
Messages (Messages That Are Not Entered in the Error Queue but Displayed in the
Error Log)
Error Message Corrective Action Page
Log sweep zero cross Set the start and stop values with values with the same sign. 6-2
Log sweep start level illegal Set the start value to a value other than 0. 6-2
Log sweep stop level illegal Set the stop value to a value other than 0. 6-2
Outside of number of trigger count Increase the step value so that the number of points is less than 6-3
or equal to 65535.
Cannot execute measure auto Correct the setting conflict (see -221 Setting conflict). -
ranging
Cannot average with block mode Correct the setting conflict (see -221 Setting conflict). -
Illegal compare level Set the comparison operation settings so that the upper limit is 8-7
greater than the lower limit.
Program sweep cannot be Select a sweep pattern file. 6-5
executed
Calculation cannot be executed Select a MATH definition file. 8-4
Illegal CAL data It is possible that the specifications may not be met even when -
the GS610 is calibrated with the default calibration values.
Request to have the GS610 recalibrated.
17.2 Error Code Description and Corrective Action
To Next Page
