3-2 IM 765501-01E
General Handling Precautions
Do Not Place Objects on Top of the Instrument
Never place objects containing water on top of the instrument, otherwise a breakdown
may occur.
Do Not Apply Shock or Vibration
Do not apply shock or vibration. Doing so may cause malfunction. In addition, applying
shock to the input/output terminal or the connected cable can cause electrical noise to
enter or output from the instrument.
Keep Electrically Charged Objects Away from the Instrument
Keep electrically charged objects away from the input connectors. They may damage the
internal circuitry.
Turn OFF the Power during Periods of Extended Non-Use
Turn OFF the power switch and remove the power cord from the outlet.
Carry the Instrument Properly
Remove the power cord and connecting cables. The instrument weighs approximately
7 kg. To carry the instrument, use the handle as shown in the figure below, and move it
carefully.
LIMIT
VS IS
MENU
SOURCE
RANGE
OUTPUT CONTROL
SOURCE
TRIG
AVERAGE
4 WIRE
KEY LOCK
DISPLAY
ESC
MEASURE
STORE
AUTO
RANGE
MENU
REGALL
MATH
NULL
COMPARE
MEASURE
VALUE
REMOTE
LOCAL
POWER
MISC
TIME
KEY LOCK
SHIFT
MODE
AUTO
RANGE
SWEEP
START
ZERO
MODE
OUTPUT
BS
V
I
SENSE
OUTPUT
Hi
110V
MAX
1V
MAX
110V
MAX
250V
MAX
7
8
9
4
5
6
1
2
3
0
.
+
-
Lo
Cleaning
When wiping off dirt from the case or operation panel, turn OFF the power switch and
remove the power cord from the outlet. Then, gently wipe with a soft dry clean cloth. Do
not use volatile chemicals since this might cause discoloring and deformation.
3.1 Handling Precautions
