3-18 IM 765501-01E
Displaying the Setup Menu of Panel Keys
1. Press a key to display a corresponding setup menu.
2. Press the soft key corresponding to the desired setup menu item.
C
A
B
A: Press the corresponding soft key to switch the setting. The underlined item is
selected.
B: Press the corresponding soft key to display the selection menu. Press the soft
key corresponding to a selection to make the selection.
C: Press the corresponding soft key to select the item to be changed with the
numeric keys or rotary knob. Enter the value directly by pressing the numeric
keys or set the value by turning the rotary knob. Press the BS (backspace) key
and right arrow key to move across the digits.
Note
If the setup menu shows Next 1/2, you can press the Next 1/2 soft key to show the 2/2 menu.
To show the 1/2 menu again, press the Next 2/2 soft key.
Clearing the Setup Menu
Press ESC (DISPLAY) to switch to the numeric display. If the menu that is
shown is under multiple menu levels, press ESC(DISPLAY) to move up a level
in the menu hierarchy. To switch to the numeric display, press ESC(DISPLAY)
multiple times.
Note
In the procedural explanations in this manual, the procedure to clear the setup menu are not
described.
3.8 Basic Operation of Keys and Rotary Knob
To Next Page
