6.20 Activating a Trigger on an Event Cycle, Delay,
or Sequence
Procedure
Selecting the Trigger Type
1.
Press EVENT INTERVAL.
2.
Press the Type soft key.
3.
Press the Event Cycle, Event Delay, or Event Sequence soft key.
Selecting the Event Mode
4.
Press the Mode soft key.
5.
Press the appropriate mode soft key from More than to Time Out.
If you select Event Cycle in step 3, proceed to step 9 on page 6-76.
Selecting the Try Mode
(If you select Event Delay or Event Sequence in step 3)
6.
Press the Mode soft key under Try Mode to select ON or OFF.
If you select ON, the DL9000 triggers on the 1st or 2nd event that you will set in the next
step.
Set Try Mode to ON to check whether triggering will occur on the 1st and 2nd events
separately.
7.
Press the Event soft key to select 1st or 2nd.
8.
Press ESC to return to the previous screen.
ESC
Event mode
Try mode
Selectable for Event
Delay and Event
Sequence.
To Next Page
