16.1 External Trigger Input (TRIG IN)

CAUTION

Do not input any signal not meeting the specification below. An excessive voltage,

for example, may damage the DL9000.

External Trigger Input Connector

This connector is used when an external signal is used as a trigger source (see section

6.6).

TRIG IN

Item Specifications

Connector type BNC

Maximum input voltage �40 V (DC + ACpeak) or 28 Vrms when the frequency is 10 kHz

or less

nput frequency bandwidth DC to 100 MHz

Input impedance Approx.1MΩ,approx.18pF

Trigger sensitivity 0.1 Vp-p

Trigger level �2 V (setting resolution 5 mV)
