19-10
IM 701310-01E
19.10 Computer Interfaces
PC card interface
Item Specifications
Number of ports 2 (front panel
×
1, rear panel
×
1)
Compatible cards
1
GP-IB card (option support)
National Instruments NI PCMCIA-GPIB cards supported
Storage cards
Flash ATA memory cards (PC card TYPE II), CF card + adapter card, HDD-type PC cards
1 For details on compatible devices, contact your nearest
YOKOGAW
A dealer.
USB-PC Connection
Item Specifications
Connector type USB type B connector (receptacle)
Electrical and mechanical
Specifications
USB Rev. 2.0 compliant
Supported transfer
standards
HS (High Speed) mode (480 Mbps), FS (Full Speed) mode (12 Mbps)
Number of ports 1
Supported protocol Acts as a composite device simultaneously supporting the following two protocols.
USBTMC-USB488 (USB Test and Measurement Class Ver. 1.0)
1
USB bus can be used with GPIB commands.
Mass Storage Class Ver. 1.1
Access from a PC to the internal memory, built-in hard disk, PC card
2, 3
, USB mass-storage
device
3
is possible (reading and writing). However, formatting is not possible.
Compatible PC systems A PC running Windows XP/2000 English/Japanese version, equipped with a USB port.
1 A separate driver is required.
2 No drivers are required.
3
For details on compatible devices, contact your nearest YOKOGAW
A dealer.
Ethernet Interface (/C8 or /C10 option)
Item Specifications
Connector type RJ-45 connector
Number of ports 1
Electrical and mechanical
Specifications
IEEE802.3 compliant
Transmission method Ethernet (100BASE-TX/10BASE-T)
Communications protocol TCP/IP
Supported services DHCP, DNS, Microsoft network file sharing server and client, SMTP client, SNTP client, FTP server,
Web server, network printer, and firewall
LED indicators 2 indicators. Link (Yellow: lit when link is established), Activity (Green: lit while packets being
transferred)
LXI Interface (/C9 or /C12 Option)
Item Specifications
Compliant standard LXI Standard, Revision 1.2 Standard, Revision 1.2
Functional class Class C
