Acquisition and Display

7-47

IM 701310-01E

App

Index

7.16 Setting Telecom Test

GO/NO-GO Determination

Conditions

Procedure

Setting the GO/NO-GO Determination Mode

Press SHIFT+TRIG MODE/HOLD OFF (ACQ COUNT/ACTION).

Press these soft keys: Action on TRG > Telecom Test > Condition.

• Selecting a GO/NO-GO Condition Number

Press the Select soft key.

Press the soft key that corresponds to the appropriate GO/NO-GO condition

number.
