19.8 Auxiliary Inputs and Outputs
External Trigger Input (TRIG IN)
Item Specifications
Connector type BNC
Input bandwidth
1
DC to 100 MHz
Input impedance Approx.1MΩ,approx.18pF
Maximum input voltage �40 V (DC+ACpeak) or 28 Vrms at a frequency of 10 kHz or less
Trigger level �2 V (resolution: 5 mV)
1 Under standard operating conditions (see page 19-1
1) after warm-up.
External Trigger Output (TRIG OUT)
Item Specifications
Connector type BNC
Output level TTL (0 - 5V)
Output logic Negative
Output delay time 50 ns max
Output hold time Low level: 50 ns min, High level: 50 ns min
Comparator Outputs (COMP OUT)
Item Specifications
Connector type 12214-8210-00TA (manufacturer 3M)
Output connectors 14 (CH1-4 trigger comparator output, trigger out output, trigger enable output, 3.3 V, GND)
Output level 3.3 V LVPECL (difference output)
Output delay time 50 ns max
Output hold time Low level: 50 ns min, High level: 50 ns min
Probe Interface Terminal
Item Specifications
Output terminals 4
Output voltage �12 V (up to total 1.2 A together with probe power terminal), �5 V (up to total 800 mA)
Compatible probes Active probe (701912/701913/701914), differential probe (701923/701924)
,
current probe (701928/701929)
Probe Power Terminal (/P2 option)
Item Specifications
Output terminals 2
Output voltage �12 V (up to total 1.2 A together with probe interface terminal)
Compatible probes and
deskew correction signal
source
FET probe (700939), current probe (701932/701933), differential probe (700924/700925/701920/
701921/701922/701926), and deskew correction signal source (701935)
GO/NO-GO Output
Item Specifications
Connector type RJ-12 modular jack
Signal types GO OUT, NO-GO OUT
Output levels TTL (0 - 5 V)
Compatible cable Four-wire modular cable (366973)
Video Signal Output (VIDEO OUT)
Item Specifications
Connector type 15-pin D-Sub receptacle
Output format Analog RGB output
Output resolution Sub-XGA output 1024
×
768 pixels, approx. 60 Hz Vsync (dot clock frequency 62.5 MHz)
