Displaying Reference Waveforms

App

Index

14-5

IM 701310-01E

14.4 Saving Data

Procedure

Press the key from M1 to M4 to display reference waveforms.

Press the Next 1/2 soft key.

Press the Save soft key.

Press one of the soft keys of the internal memory #1 to #4.

The reference waveform is stored in the selected internal memory.

Note

A waveform exceeding 1.25 MW is saved with P-P compression to 1.25 MW.
