5-5

IM 701310-01E

Vertical and Horizontal Axes

App

Index

5.4 Setting the Input Coupling

Procedure

Press one of the CH1 to CH4 keys to select the channel.

Press the Coupling soft key.

Press the soft key corresponding to the desired coupling.

This option should be

set to INPUT.

Note

When a probe supported by the DL9000 probe interface is used, the input coupling is set

automatically.
