10.10 Selecting the Search Type and Skip Mode,

Executing the Search, and Displaying the

Results

Procedure

CURSOR

PARAM

TELECOM

TEST

WINDOW 1

WINDOW 2

FORM

ACCUM

CLEAR

ZOOM 1

ZOOM 2

DISP

MAG

INTENSITY

MEASURE

ANALYSIS

DISPLAY ZOOM

ACCUM

Press ZOOM1 or ZOOM2.

The ZOOM menu appears.

Press the H/V soft key to select H.

Selecting a Search Type

Press these soft keys: Setup > Search Type.

The Search Type menu appears.

From the menu that appears, press the appropriate soft key to select the search

type.

Proceed to the appropriate section indicated below according to the selected

search type, and then set the search options.

• Edge, Edge (Qualified), State, Width: Section 10.11

• Serial: Section 10.13

• I2C, CAN, LIN. SPI, UART:

An optional serial bus analysis function. See the option manual IM 701310-51E.
