Acquisition and Display

7-27

IM 701310-01E

App

Index

Explanation

The DL9000 returns GO/NO-GO results based on whether or not the source waveform

falls within the zone that you set using a reference waveform.

Reference Waveform

Select the waveform that you will use as a basis for the GO/NO-GO determination zone.

You can select the reference waveform from CH1 to CH4 or from M1 to M4. You cannot

select a waveform that is not displayed.

Creating a GO/NO-GO Determination Zone

You can create a maximum of four GO/NO-GO determination zones. The boundaries of

the zones can be set within the following ranges:

• Upper and lower boundaries:

�8 divisions from the reference waveform

•

Left and right boundaries: �5 divisions from the center of the screen

ou can choose to apply the GO/NO-GO determination zones assigned to GO/NO-

GO condition numbers 1 to 4 to input signal waveforms (CH1 to CH4) and computed

waveforms (M1 to M4). Any zone whose condition setting is either IN or OUT appears on

the display.

Source Waveform

You can choose a waveform from CH1 to CH4 or from M1 to M4.

GO/NO-GO Condition Number

You can choose to configure a GO/NO-GO condition from 1 to 4.

GO/NO-GO Determination Area

You can set the GO/NO-GO determination area to less than or equal to �5 divisions from

the time axis.

GO/NO-GO Determination Condition

• IN: The DL9000 returns a no-go result when the source waveform is within the GO/

NO-GO determination zone.

• OUT

: The DL9000 returns a no-go result when the source waveform is outside of the

GO/NO-GO determination zone.

• X: GO/NO-GO determination does not take place.

7.10 Setting Waveform Zone GO/NO-GO Determination Conditions
