The DL9000 returns GO/NO-GO results based on whether or not the source waveform is
in the rectangular zone that you set by specifying the zone’s lower, upper, left, and right
boundaries.
GO/NO-GO Determination Zone
You can set the area used for GO/NO-GO determination. The selectable boundaries are
as follows:
• Left and right boundaries:
�5 divisions from the center of the screen; the boundaries
can be set in 0.01-division steps.
•
Upper and lower boundaries:
�4 divisions from the center of the screen; the
boundaries can be set in 0.01-division steps.
Note
Rectangular zones will disappear if you set their Condition setting to X or if you turn the display
for their source waveform OFF.
GO/NO-GO Condition Number
You can choose to configure a GO/NO-GO condition from 1 to 4.
Source Window
• Main: Sets the main waveform as the source.
• Zoom1: Sets the waveform in zoom box 1 as the source.
• Zoom2: Sets the waveform in zoom box 2 as the source.
• XY1: Sets the waveform in the XY1 window as the source.
• XY2: Sets the waveform in the XY2 window as the source.
Source Waveform
You can choose a waveform from CH1 to CH4 or from M1 to M4.
GO/NO-GO Determination Condition
• IN: The DL9000 returns a no-go result when the source waveform is within the GO/
NO-GO determination zone.
• OUT
: The DL9000 returns a no-go result when the source waveform is outside of the
GO/NO-GO determination zone.
• X: GO/NO-GO determination does not take place.
7.11 Setting Rectangular Zone GO/NO-GO Determination Conditions
