7-50
IM 701310-01E
Explanation
The DL9000 returns GO/NO-GO results depending on whether or not the telecom test
test parameters are within the range that you set.
GO/NO-GO Condition Number
You can choose to configure a GO/NO-GO condition from 1 to 4.
GO/NO-GO Target Parameters
• Telecom Test Mask Test/Eye Pattern Results
• Mask Test
You can set Mask
Test options for Element1 to Element4. For details about these
options, see section 10.4.
• T
elecom
Test
You can set Eye Pattern options. For details about these optio
ns, see section 10.4.
GO/NO-GO Determination Range
You set the range by specifying the maximum and minimum values for the specified test
items.
GO/NO-GO Determination Condition
• IN: The DL9000 returns a no-go result when the test items are in the set range.
• OUT: The DL9000 returns a no-go result when the test items are outside of the set
range.
• X: GO/NO-GO determination does not take place.
Note
Because the sample point count is calculated using interpolated data, the value returned for it
may not correspond to the record length.
7.16 Setting Telecom Test GO/NO-GO Determination Conditions
